Our NEW Fast Gear Access side plate makes servicing your Fathom II LW easier than ever. With the removal of 4 screws, the gear side plate is easily removed giving access to the gear box for any needed maintenance without the worry of losing springs or other parts. VERSA DRAG By rearranging the sequence of the keyed metal washers and eared HT-100 washers the reel can be set up for fishing a wide range of drag settings without additional parts.
- HT-100™ carbon fiber drag washers
- Full Metal Body and sideplates
- Line Capacity Rings
- Fast Gear Access Side Plate
- 4+1 stainless steel bearing system
| MODEL # | MONO CAPACITY YD/LB | BRAID CAPACITY YD/LB | BEARING COUNT | MAX DRAG LB | GEAR RATIO |
| FTHII15LW | 380/12 325/15 215/20 | 590/20 445/30 310/50 | 5 | 30lb | 13.6kg | 5.5:1 |
| FTHII20LW | 475/15 315/20 290/25 | 860/20 645/30 450/50 | 5 | 30lb | 13.6kg | 5.5:1 |
| FTHII30LW | 465/25 375/30 290/40 | 1040/30 725/50 605/65 | 5 | 30lb | 13.6kg | 4.3:1 |
| FTHII50LW | 430/40 320/50 285/60 | 895/65 770/80 660/100 | 5 | 30lb | 13.6kg | 3.7:1
|
